1.   Applications:

EOD explosive detection for anti-terrorism, defusing; VIP safeguarding; SWAT, CAT special commando; and special places for radio signal interference shielding.

2. Main technical characteristics:

2.1 multi interference-modulated signal generation methods:

Unique advanced & efficient interference signal modulation methods were adopted for the actual needs in different frequency bands in order to improve the interference efficiency and ensure the reliable interference result.

l  20-80MHz with modulated white noise (white noise) interference pattern.

l  80-800MHz using direct digital synthesis (DDS) mode noise.

l  800-2500MHz using direct digital waveform synthesis (DDWS) noise model.

2.2 Main frequency bands will cover all the applied areas by its expansion capability, free module combination, and interference brand module design.

2.3 Convenient for battle operation staff by its advanced antenna technology and minimizing external equipment number

2.4 Multiple internal self-protection function (power output/input voltage, current protection) will avoid the possibility to damage the system by wrong antenna connection.

2.5 Device appearance: innovative, high quality and modern. Mixed resin materials to make devices dust-proof, waterproof, anti-shock, anti-corrosion, moisture-proof, explosion-proof effect. Ergonomic design for overall use of the ventilation cooling groove and shoulder strap can emit moisture from the back of the body; such design is suitable for a variety of extreme weather environments.

3. Technical Specifications:

3.1 frequency, power and interference objectives:

Note: Key interfering frequencies can be adjusted based on customer’s national location

3.2 Power: 300W.

3.3 Interference way: a combination of a variety of modulation methods to suppress interference.

3.4 Voltage: DC24-28V @ 15AMP

3.5 Built-in Battery: 26V @ 12AH, can continuously support operation in 60 minutes.

3.6 External box was produced by Italian HPRC, which is the first shatterproof & waterproof backpack.

3.7 Volume: 370x500x185 (mm);

3.8 Weight: 25 kg.

3.9 environmental temperature ranges:  -30 ℃ to +60 ℃. Be able to withstand extreme temperature changes.

3.10 Interference Distance:

l  20-520MHZ in the open areas it can effectively interfere with simple radio-controlled device coverage radius of at least 40 meters.

l  800-2500MHZ in the open areas it can effectively interfere with mobile phone coverage radius of at least 30 meters; in the signal strength of-80dB intensity environment it can cover about 40 meters in radius.

4. standard accessories:

4.1 DC-350W power adapter DC28V15A (including 1x 25.9V5A charger)

4.2 External antenna A.B.C included.
